Always have two people available tocarry, lift or turn over the transceiver.ĭO NOTuse harsh solvents such as benzine or al-Ĭohol when cleaning, as they can damage the trans-ceivers surfaces.ĭO NOTpush the PTT switch when you dont actu-ally desire to transmit.ĭO NOTuse or place the transceiver in areas withtemperatures below 0C (+32F) or above +50C(+122F).ĭO NOTplace the transceiver in excessively dustyenvironments or in direct sunlight.ĭO NOTplace the transceiver against walls or put-ting anything on top of the transceiver. Heat dissipationmay be reduced, and the transceiver may be dam-aged.ĬAUTION: The line-voltage receptacle must benear the transceiver and must be easily accessible.ĬAUTION: The transceiver weighs approximately25 kg (55 lb).
#Ic 7800 service manual install#
The transceiver warranty does not cover any problemscaused by unauthorized internal adjustment.ĬAUTION: NEVERblock any cooling vents on thetop, rear or bottom of the transceiver.ĬAUTION: NEVERexpose the transceiver to rain,snow or any liquids.ĬAUTION: NEVER install the transceiver in aplace without adequate ventilation. In particular, incorrect settings for transmitter circuits,such as output power, idling current, etc., might dam-age the expensive final devices. This may reduce transceiver perfor-mance and/or damage to the transceiver. This may cause injury and/or damage to thetransceiver.ĬAUTION:NEVER change the internal settings ofthe transceiver.
Contact your Icomdealer or distributor for advice.ĬAUTION: NEVER put the transceiver in any un-stable place (such as on a slanted surface or vibrated RWARNING!Immediately turn the transceiverpower OFF and remove the power cable if it emits anabnormal odor, sound or smoke. RWARNING! NEVER let metal, wire or otherobjects protrude into the transceiver or into connec-tors on the rear panel. This may result in an elec-tric shock or damage to the transceiver. R WARNING! NEVER operate or touch thetransceiver with wet hands. If you experience a ringing inyour ears, reduce the volume or discontinue use. Hearing experts advise against continuoushigh volume operation. RWARNING! NEVER operate the transceiverwith a headset or other audio accessories at high vol-ume levels. This may result in an electrical shockor burn. and the Icom logo are registered trademarks of Icom In-corporated (Japan) in Japan, the United States, the United Kingdom, Ger-many, France, Spain, Russia, Australia, New Zealand, and/or other coun-tries.Īttach an antenna or internal antenna connector dur-ing transmission. No risk of personalinjury, fire or electric shock. RWARNING! Personal injury, fire hazard or electric shock may occur. WORD DEFINITIONRDANGER! Personal death, serious injury or an explosion may occur.
#Ic 7800 service manual manual#
SAVE THIS INSTRUCTION MANUAL.This manual contains im-portant safety and operating instructions for the IC-7800. IMPORTANTREAD THIS INSTRUCTION MANUAL CAREFULLYbefore at-tempting to operate the transceiver.
#Ic 7800 service manual plus#
Upgraded real-time spectrum scope center frequency andfix frequency modes, plus mini-scope displays
#Ic 7800 service manual Pc#
Independent identical receiver circuits for main and subbands provide perfect no-compromise Dualwatch operationīuilt-in Baudot RTTY and PSK31 modulator/demodulatorand direct PC keyboard connection capability for RTTY andPSK31 operation without a PC Ultimate receiver performance: third-order intercept (IP3) of+40 dBm (HF bands only), both main and sub Many hours of research and development wentinto the design of your IC-7800. We would like to take a few moments of your time to thank you for makingthe IC-7800 your radio of choice, and hope you agree with Icoms philos-ophy of technology first. With proper care, this prod-uct should provide you with years of trouble-free operation. The IC-7800 is designed and built withIcoms superior technology and craftsmanship. Congratulations! You are the owner of the worlds most advanced amateur
